Tumbler Wrap Size Calculator and Chart Guide

How to use the Tumbler Wrap Size Calculator and Chart

Choose inches or millimeters before entering measurements.
Select straight or tapered mode, then enter the measured top diameter, bottom diameter when needed, side height, overlap, and bleed.
If you measured circumference, divide it by pi before entering a diameter field.
Download the SVG template or print-test PDF, print at actual size, and check the calibration mark.
Use the PNG preview and Job notes TXT as support files for sharing, order notes, or press-station setup.

Hands measuring a stainless tumbler with labels for top diameter, bottom diameter, and side height — Measure the cup, not the label: top diameter, bottom diameter, and side height.

Straight and tapered examples

Measured straight tumbler

Inputs

Mode: Straight tumbler
Top diameter: 2.95 in
Side height: 8.20 in
Overlap: 0.25 in

Result

The calculator returns a rectangular wrap around 9.52 in wide by 8.20 in high.

Production check

Print on paper first and wrap it around the blank before sublimating.

Measured tapered tumbler

Inputs

Mode: Tapered tumbler
Top diameter: 3.10 in
Bottom diameter: 2.80 in
Side height: 7.60 in
Overlap: 0.20 in

Result

The calculator returns top and bottom arc lengths, sector angle, curve radii, and an estimated curved SVG template.

Production check

If the seam does not line up on paper, adjust the measured cup values before pressing the final wrap.

Units and parameters

Keep units consistent from design setup through pressing notes. When the tool provides a preset, use it as a planning value and replace it with the actual garment or blank measurement when possible.

Input or rule	What it changes
Unit	Choose the option that matches the job. Starting value: in. Options include Inches, Millimeters.
Tumbler shape	Choose the option that matches the job. Starting value: straight. Options include Straight tumbler, Tapered tumbler. Straight mode makes a rectangular wrap. Tapered mode makes a curved sector template.
Top diameter	Enter a measurement or quantity. Starting value: 2.95. For straight tumblers, use this as the cup diameter.
Bottom diameter	Enter a measurement or quantity. Starting value: 2.75. Used for tapered mode when the top and bottom diameters differ.
Side height measured along the cup wall	Enter a measurement or quantity. Starting value: 8.2. Measure from the top edge to the bottom edge along the side of the cup, not straight down through the air.
Overlap	Enter a measurement or quantity. Starting value: 0.25.
Bleed	Enter a measurement or quantity. Starting value: 0.
PDF paper size	Choose the option that matches the job. Starting value: letter. Options include US Letter, A4.
Formula	Straight mode makes a rectangular wrap from cup diameter, overlap, and bleed on both sides. Tapered mode treats the cup as a straight-sided truncated cone and unrolls it into a curved sector template.
Production check	Straight mode is for straight skinny tumblers or blanks with nearly equal top and bottom diameters.

Rule and assumptions

Straight mode makes a rectangular wrap from cup diameter, overlap, and bleed on both sides. Tapered mode treats the cup as a straight-sided truncated cone and unrolls it into a curved sector template.

Straight mode is for straight skinny tumblers or blanks with nearly equal top and bottom diameters.
Tapered mode is for cups where top and bottom diameters are different and the flat template needs a curve.
A curved template is still a planning template. Handles, brand-specific curves, ridges, lips, rubber bases, and irregular walls can change the real paper fit.
Do not scale print output unless intentionally resizing; use the 1 inch / 25.4 mm calibration mark.

Use this tool for

Calculating custom tumbler wrap size from top and bottom diameters.
Estimating cup wrap width with seam overlap.
Checking tapered tumbler measurements before printing.
Downloading an SVG template or print-test PDF with a calibration mark.

Paper-test note

Inputs

Use the current calculator fields: unit, tumbler shape, top diameter, bottom diameter for tapered cups, side height, overlap, and bleed.

Result

The calculator gives a straight wrap rectangle or an estimated tapered sector, plus SVG, print-test PDF, PNG preview, and Job notes TXT outputs.

When to use this

Use it when you need a one-piece planning template from measured tumbler dimensions before printing or cutting the final wrap.

What to check before pressing

Print a paper test at actual size, check the 1 inch / 25.4 mm mark, and treat handled 40 oz blanks as rough planning unless exact panel measurements are known.

Quick reference chart

Use case	Starting point	Check before pressing
Straight cup	Use average diameter	Verify circumference
Tapered cup	Measure top and bottom	Paper-test the curve
Handled cup	Use as a front-panel estimate	Do not wrap artwork through the handle

Common mistakes

Entering circumference in a diameter field.
Using a negative or oversized overlap value.
Ignoring taper when top and bottom diameters differ.
Treating a 40 oz handled tumbler as a simple one-piece wrap when exact panel measurements are not known.

Next production step

Move from this result into the next heat press decision: size, placement, press setup, printable notes, or pricing.

Open resource packHeat press templatesDownload the static tumbler SVG and related printable worksheets after generating the custom wrap.Compare chartSublimation tumbler size chartCheck common 20 oz, 30 oz, 40 oz, mug, straight, and tapered starting ranges before production.Price listingSeller pricing calculatorAfter the wrap size is set, estimate blank, material, labor, packaging, and fee assumptions.

FAQ

Should I enter tumbler diameter or circumference?

Enter diameter in the calculator fields. If you already measured circumference, do not paste that number into a diameter field; divide circumference by pi first.

What size is a 20 oz skinny tumbler wrap?

A common starting point for a straight 20 oz skinny tumbler wrap is about 9.25-9.45 inches wide by 8.1-8.4 inches high. Measure the actual cup, add seam overlap or bleed only after checking the paper fit, and print a test wrap before sublimating.

How do I size a tapered tumbler wrap?

Choose Tapered tumbler mode, then measure top diameter, bottom diameter, and side height along the cup wall. The calculator unrolls the cup as a straight-sided truncated cone, so the output is a curved sector template rather than an average-diameter rectangle.

Why is my tumbler wrap curved?

A tumbler wrap is curved when the top and bottom diameters are different. Tapered mode unrolls the cup as a truncated cone, so the template becomes a curved sector instead of a rectangle.

What is seam overlap?

Seam overlap is the extra width added so the wrap closes cleanly around the cup. A small overlap helps prevent a visible gap after pressing.

Should I print at 100% scale?

Yes. Print the SVG template or print-test PDF at 100% scale, then check the 1 inch / 25.4 mm calibration mark before pressing or sublimating the final wrap.

Is bleed the same as overlap?

Not exactly. Overlap helps the seam close around the cup; bleed is extra artwork beyond the trim or visible edge. Some workflows use both, depending on printer and template setup.

Why is my size different from a template seller's dimensions?

Template sellers may target a specific cup brand, printable height, seam style, bleed, or handle cutout. Your measured cup can differ even when the ounce label is the same.
